■ IR resistance test range: 10kΩ - 100TΩ
■ Charge current: 2mA , 25mA, 100mA
■ Test speed: 50ms
■ Accuracy: ±2% (< 1TΩ )
■ Test voltage range: 10-1000V, 1V step
■ 320×240 dot-matrix LCD
■ Ultra-low leakage current test: minimum current is
10pA, accuracy: 2% ±2pA
■ Dual outputs (precharge voltage output and test
voltage output) can be set.
■ The precharge voltage output can be set to follow the test
voltage output and can be finely adjusted on test voltage.
Also the precharge voltage can be set to work in
independent mode.
■ 100W powerful charging function
■ Contact detection function for capacitive components
■ When the test current is less than 10nA, the internal input
impedance can be selected between 10kΩ and 1MΩ to
ensure rapid and accurate test.
■ 7 current ranges, manual or auto range mode
■ 4-bin comparison function
■ Programmable sequence test mode
■ R-T and I-T Curve test and display mode
■ Screen hardcopy to be saved as BMP file to a U disk
■ Automatically upgrade firmware by a U disk
■ Achieve automatic test system by Handler interface
■ Achieve remote control by RS232C and USB
Device interface
■ Support scanning interface for mass tests
■ Auto store setup parameters
■ Selectable Chinese and English operation interfaces
